ICS-600 Logic Board for V3F Elevator
9500.00 - 10000.00 INR/Piece
Product Details:
- Material Stainless Steel
- Surface Finish Electro Zinc Plated
- Surface Color Green
- Click to View more
X
ICS-600 Logic Board for V3F Elevator Price And Quantity
- 9500.00 - 10000.00 INR/Piece
- 1 Piece
ICS-600 Logic Board for V3F Elevator Product Specifications
- Electro Zinc Plated
- Green
- Stainless Steel
Product Description
1. Logic board for V3F ELEVATOR.
2. Supply voltage requirement 12VAC/DC, 24VDC & 110VAC for safety.
3. On board number of stops 8.
4. Maximum 16 stops with extension card. (G+15 down collective / G+10 full collective).
5. Door operation MANUAL door & AUTO door.
6. Speed support up to 1 m/s.
7. Reed signals FLOOR REED & CABIN TOP REED as per requirement.
8. Relay board & announcement embedded with the logic board so no need of external relay card & announcement card.
9. A-plus voice IC used for floor,DOB,OVERLOAD,
10. ARD announcement & Running music (3 music)
11. Compact design with the less control wiring.
12. Functions
- Auto attendant.
- Auto fan.
- Fire mode.
- Stop.
Technical Specifications
Display Type | LCD |
Brand | Icon |
Usage/Application | Elevator |
Model Name/Number | ICS 600 |
Board Thickness | 1.2 mm |
Material | Thermoplastic |
Packaging Type | Box |
Country of Origin | Made in India |
Indicator | Yes |
Function | Auto attendant, Auto fan & light, Fire mode, Call cancel & Nonstop |
Finish | Electro Zinc Plated |
